AMD Ryzen Threadripper PRO 9975WX
Benchmark Score
Price
₹ 424,500
Description
Cores / Threads 32 Cores / 64 Threads
Architecture Zen 5 (Shimada Peak)
Base Clock 4.0 GHz
Max Boost Clock Up to 5.4 GHz
TDP (Default) 350W (Requires premium 360mm+ liquid cooling)
Socket sTR5
Motherboard Chipset WRX90 (for full 8-channel & 128 PCIe lanes)
PCI Express 128 Lanes of PCIe Gen 5.0
Process Node TSMC 4nm (Core) / 6nm (I/O)
Memory Type DDR5 (ECC Registered/RDIMM required)
Memory Channels 8-Channel (Octa-Channel)
Max Memory Speed Up to 6400 MT/s
Max Capacity Up to 2 TB (per socket)
Bandwidth ~409.6 GB/s (at 6400 MT/s)
Features AMD Memory Guard (Real-time encryption)
L1 Cache: 2.5 MB total (80 KB per core: 48 KB Instruction + 32 KB Data).
L2 Cache: 32 MB total (1 MB dedicated per core).
L3 Cache: 128 MB total (Large shared pool for high-speed data access).
Brands
AMD Ryzen Threadripper PRO 9975WX
Score
Cores & Threads
Integrated Graphics
Class
TDP Power
Clockspeed base
4.0 GHz
Turbo Speed
Up to 5.4 GHz
Socket Type INTEL
Socket Type AMD
Cache Memory
L1 Cache: 2.5 MB total (80 KB per core).
L2 Cache: 32 MB total (1 MB dedicated per core).
L3 Cache: 128 MB total (Shared pool).
Total Cache: ~162.5 MB (Combined L1 + L2 + L3).
RAM support
Memory Type DDR5 (ECC Registered/RDIMM required)
Memory Channels 8-Channel (Octa-Channel)
Max Memory Speed Up to 6400 MT/s
Max Capacity Up to 2 TB (per socket)
Bandwidth ~409.6 GB/s (at 6400 MT/s)
Features AMD Memory Guard (Real-time encryption)
