AMD Ryzen Threadripper 9980X

Benchmark Score

149991

Price

₹ 518,960

Description

Specification :

General
CPU Model AMD Ryzen Threadripper 9980X
CPU Socket sTR5
Manufacturing Process 4 nm
Maximum CPU Configuration 1S
Maximum Number of PCIe Lanes 88 (Revision 5.0)
Unlocked Yes
Performance
Number of Cores 64
Number of Threads 128
Base Clock Speed 3.2 GHz
Maximum Boost Speed 5.4 GHz
Dedicated AI Cores No
L3 Cache 256 MB
Memory Support
Memory Support DDR5 Up to 6400 MT/s
ECC Memory Yes
Channel Architecture Quad Channel
Power
Thermal Design Power (TDP, Max) 350 W
Included Thermal Solution No
Maximum Temperature 203°F / 95°C
Thermal Monitoring Technologies Yes
Technology
AES Support Yes
Extension AVX, AVX 2.0, AVX-512, FMA3, SSE 4.1/4.2
Instruction Set 64-Bit
Virtualization Yes: AMD-V
Performance Technologies Precision Boost 2

Brands

(Excellent)

AMD

AMD Ryzen™ Threadripper™ 9980X

Score

(Excellent)

100000 to 176,169

Cores & Threads

(Very Good)

64-Core / 128-Thread

Integrated Graphics

(Poor)

Class

(Excellent)

Desktop

TDP Power

(Very Good)

300w to 400w

Clockspeed base

(Very Good)

3.0 GHz to 3.5 GHz

3.2 GHz

Turbo Speed

(Very Good)

5.0 GHz to 5.5 GHz

Up to 5.4 GHz

Socket Type INTEL

(Poor)

Socket Type AMD

(Very Good)

STR5

Cache Memory

(Very Good)

L1, L2, L3,>-240 MB to 480 MB

L1 Cache 80 KB 5.12 MB 48KB Data + 32KB Instruction
L2 Cache 1 MB 64 MB Private to each core
L3 Cache 4 MB (avg) 256 MB Shared per 8-core CCD
Total Cache — ~325.12 MB Combined L1 + L2 + L3

RAM support

(Very Good)

DDR5

Memory Type DDR5 (Registered DIMM / RDIMM only)
Memory Channels 4-Channel (Quad-Channel)
Max Official Speed 6400 MT/s
Max Capacity Up to 1 TB
ECC Support Yes (Required)
Memory Overclocking Supports AMD EXPO™ & Precision Boost Overdrive
Bandwidth ~204.8 GB/s (Theoretical peak)
