AMD EPYC Embedded 9755
Benchmark Score
Price
₹ 1,120,000
Description
Cores / Threads 128 Cores / 256 Threads
Architecture Zen 5 (Turin)
Base Clock 2.7 GHz
Max Boost Clock Up to 4.1 GHz
Socket SP5 (LGA 6096)
TDP (Default) 500W (Configurable from 450W to 500W)
PCI Express 128 Lanes of PCIe Gen 5.0
Process Node 4nm (Core) / 6nm (I/O)
RAM Type DDR5 (Registered ECC RDIMM)
Memory Channels 12-Channel
Max Memory Speed 6400 MT/s
Max Capacity Up to 6 TB per socket
Peak Bandwidth ~614 GB/s
Brands
AMD EPYC Embedded 9755
Score
164022
Cores & Threads
CPU Cores
128 Threads
256
Integrated Graphics
Class
TDP Power
Clockspeed base
Base Clock
2.7 GHz
Turbo Speed
Boost Speed
4.1 GHz
Socket Type INTEL
Socket Type AMD
CPU Socket
SP5 Socket Count
1P / 2P
Cache Memory
Cache Level Per Core Total (128 Cores) Type
L1 Cache 80 KB ~ 10.25 MB 48KB Data + 32KB Instruction
L2 Cache 1 MB 128 MB Dedicated per core
L3 Cache 4 MB (avg)* 512 MB Shared per 8-core complex (CCD)
Total Cache — ~ 650.25 MB Combined L1 + L2 + L3
RAM support
Core RAM Specifications
Feature Specification
Memory Type DDR5 (Registered DIMM / RDIMM)
Memory Channels 12-Channel
Max Official Speed 6400 MT/s (1 DIMM per Channel)
2DPC Speed ~4800 MT/s (2 DIMMs per Channel)
Max Capacity Up to 6 TB (using 512GB RDIMMs)
ECC Support Yes (Required)
