AMD EPYC 9R14

Benchmark Score

116493

Price

₹ 210,000

Description

Full Technical Specifications
Category Details
Cores / Threads 96 Cores / 192 Threads
Architecture Zen 4 (Genoa)
Base Clock 2.6 GHz (Slightly higher than the 9654)
Max Boost Clock Up to 3.7 GHz
Process Node TSMC 5nm (Core) / 6nm (I/O)
TDP (Default) 360W (Configurable up to 400W)
Socket SP5 (LGA 6096)
PCI Express 128 Lanes of PCIe Gen 5.0
Scalability 1P and 2P (Single and Dual Socket) support

RAM Type DDR5 (ECC Support required)
Memory Channels 12 Channels
Max Memory Speed 4800 MT/s
Max Capacity Up to 6 TB (using 256GB/512GB 3DS RDIMMs)
Bandwidth ~460.8 GB/s (Peak)

L1 Cache: 6 MB total (64 KB per core)

L2 Cache: 96 MB total (1 MB dedicated per core)

L3 Cache: 384 MB total

Note: The L3 cache is organized as 32 MB shared per 8-core CCD cluster.

Brands

(Excellent)

AMD

AMD EPYC 9R14

Score

(Very Good)

100000 to 176,169

Cores & Threads

(Excellent)

96-Core / 192-Thread

Integrated Graphics

(Poor)

Class

(Very Good)

Server

TDP Power

(Very Good)

300w to 400w

Clockspeed base

(Very Good)

2.5 GHz to 3.0 GHz

2.6 GHz

Turbo Speed

(Very Good)

3.5 GHz to 4.0 GHz

Up to 3.7 GHz

Socket Type INTEL

(Poor)

Socket Type AMD

(Very Good)

SP5

Cache Memory

(Very Good)

L1, L2, L3,>-480 MB to 1GB

L1 Cache: 6 MB total (32 KB Instruction + 32 KB Data per core).

L2 Cache: 96 MB total (1 MB dedicated per core).

L3 Cache: 384 MB total (Shared shared pool across CCDs).

Total Cache: 486 MB (Combined L1 + L2 + L3).

RAM support

(Poor)

DDR5

RAM Type DDR5 (ECC Support required)
Memory Channels 12 Channels
Max Memory Speed 4800 MT/s
Max Capacity Up to 6 TB (using 256GB/512GB 3DS RDIMMs)
Bandwidth ~460.8 GB/s (Peak)
